dbx 231S Dual 31-Band Graphic Equaliser

$319.00
Only 1 Left!

Dual 31-band, 1/3-octave Constant Q frequency bands

Switchable boost/cut ranges of +/-6 or +/-12 dB

Front panel bypass switch

+/-12 dB input gain range

XLR and TRS Inpts and Outputs

Calculate Shipping



1 x dbx 231S Dual 31-Band Graphic Equaliser delivered to , AU


Collect - $0.00
Free in-store pick up from our Port Melbourne showroom

When the pros need an EQ, they turn to dbx. A proven track record that spans four decades, dbx® EQs are the industry standard for touring, studios, and audio installations.

The dbx 231s includes two 31-band channels of 1/3-octave equalization, +/-12 dB input gain, switchable +/-6 dB or +/-12 dB boost/cut range, 20mm nonconductive sliders, an intuitive user interface, and output level metering.

Features :

  • Dual 31-band, 1/3-octave Constant Q frequency bands
  • Switchable boost/cut ranges of +/-6 or +/-12 dB
  • Front panel bypass switch
  • +/-12 dB input gain range
  • 4-segment LED ladders for monitoring output levels
  • XLR and TRS Inpts and Outputs
  • Frequency Response of <10Hz to >50kHz
  • Dynamic range of greater than 108dB

Technical :

  • Input Connectors : 1/4" TRS, female XLR (pin 2 hot)
  • Input Impedance : Balanced 40k ohm, unbalanced 20k ohm
  • Max Input : +21dBu balanced or unbalanced
  • CMRR : >40dB, typically >55dB at 1kHz
  • Output Connectors : 1/4" TRS, male XLR (pin 2 hot)
  • Output Type : Impedance-balanced/unbalanced, RF filtered
  • Output Impedance : Balanced 100 ohm, unbalanced 50 ohm
  • Max Output : +21dBu balanced/unbalanced into 2k ohm or greater; +18dBm balanced/unbalanced (into 600 ohm)
  • Bandwidth : 20Hz to 20kHz, +0.5/-1dB
  • Frequency Response : <10Hz to >50kHz, +0.5/-3dB
  • Dynamic Range : Typically >112dB
  • Signal to Noise Ratio : Typically >95dB
  • THD+Noise : <0.003%
  • Interchannel Crosstalk : -90dB, 20Hz to 20kHz
  • Bypass Switch : Bypasses the graphic equalizer section in the signal path
  • Low cut Switch : Activates the 50Hz 12dB/octave high-pass filter
  • Range Switch : Selects either +/- 6dB or +/-12dB slider boost/cut range
  • Weight : 2.81 kg
  • Dimensions : 8.9cm H x 15.24cm D x 48.26cm W

(DBX-231S)

SKU DBX-231S
Barcode # 691991401206
Brand dbx
Shipping Weight 4.0000kg
Shipping Width 0.300m
Shipping Height 0.130m
Shipping Length 0.570m
Shipping Cubic 0.022230000m3
